Electrical Submeters

For Tenant Billing and Energy Management

Triacta multi-point electrical meters are among the most accurate and reliable available — with a low cost per meter point and easy installation.
Overview BrochureProduct Guide (PDF)
All
Revenue Grade
Energy Management Grade
Need Help or a Quote ?
GATEWAY 1000

GATEWAY 1000

A highly flexible (12, 24, 36, or 48 CT inputs) revenue-grade, multi-point electrical meter for regulated markets.

Inputs:
12, 24, 36, or 48
Config:
Any approved combination of single, two, or 3-element meter points
Voltage:
2 VRef, 300V max
CTs:
100mA Solid-Core
Approvals:
Measurement Canada (Pending)
GATEWAY 3000

GATEWAY 3000

A highly flexible (12, 24, 36, or 48 CT inputs) revenue-grade, multi-point electrical meter suitable for energy management in non-regulated markets. ‍

Inputs:
12, 24, 36, or 48
Config:
Any approved combination of single, two, or 3-element meter points
Voltage:
2 VRef, 300V max
CTs:
333mV Split-Core
Approvals:
Non-Regulated
GATEWAY 8000

GATEWAY 8000

A highly flexible (6 12, 24, 36, or 48 CT inputs) revenue-grade, multi-point electrical meter for regulated markets.

Inputs:
12, 24, 36, or 48
Config:
Any approved combination of single, two, or 3-element meter points
Voltage:
2 VRef, 300V max
CTs:
80mA Solid-Core or 5A:80mA CT Convertors
Approvals:
Measurement Canada, CDFA (Pending)
GATEWAY 9000

GATEWAY 9000

A highly flexible (6, 12, 18, or 24 CT inputs) revenue-grade, multi-point electrical meter for regulated markets.

Inputs:
6, 12, 18, 24
Config:
Any approved combination of single, two, or 3-element meter points
Voltage:
2 VRef, 300V max
CTs:
80mA Solid-Core or 5A:80mA CT Convertors
Approvals:
Measurement Canada
PowerHawk 4206

PowerHawk 4206

A low density (6 CT inputs) revenue-grade, multi-point electrical meter suitable for energy management in non-regulated markets. ‍

Inputs:
6
Config:
6 x 1-phase, 3 x 2-phase, 2 x 3-phase
Voltage:
120V CV, 90-300V Vref
CTs:
333mV Split-Core
Approvals:
Non-Regulated
PowerHawk 4224

PowerHawk 4224

A higher density (24 CT inputs) revenue-grade, multi-point electrical meter suitable for energy management in non-regulated markets. ‍

Inputs:
24
Config:
24 x 1-phase, 12 x 2-phase, or 8 x 3-phase
Voltage:
120V CV, 90-300V Vref
CTs:
333mV Split-Core
Approvals:
Non-Regulated
PowerHawk 6103

PowerHawk 6103

A low density (6 CT inputs) revenue-grade, multi-point electrical meter suitable for regulated markets.

Inputs:
6
Config:
6 x 1-phase, 3 x 2-phase, 2 x 3-phase
Voltage:
120V CV, 90-300V Vref
CTs:
100mA Solid-Core
Approvals:
Measurement Canada, NYPSC, Maryland PSC, CDFA
PowerHawk 6112

PowerHawk 6112

A high density (24 CT inputs), multi-point electrical meter that uses 100mA solid-core CTS and suitable for use in regulated markets in Canada and the US.

Inputs:
24
Config:
24 x 1-phase, 12 x 2-phase, or 8 x 3-phase
Voltage:
120V CV, 90-300V Vref
CTs:
100mA Solid-Core
Approvals:
Measurement Canada, NYPSC, Maryland PSC, CDFA
PowerHawk 6303

PowerHawk 6303

A low density (6 CT inputs) revenue-grade, multi-point electrical meter suitable for regulated markets. ‍

Inputs:
6
Config:
6 x 1-phase, 3 x 2-phase, 2 x 3-phase
Voltage:
120V CV, 90-300V Vref
CTs:
80mA Solid-Core or 5A:80mA CT Convertors
Approvals:
Measurement Canada, NYPSC, Maryland PSC, CDFA
PowerHawk 6312

PowerHawk 6312

A high density (24 CT inputs), multi-point electrical meter that uses 80mA solid-core CTS and suitable for use in regulated markets in Canada and the US.

Inputs:
24
Config:
24 x 1-phase, 12 x 2-phase, or 8 x 3-phase
Voltage:
120V CV, 90-300V Vref
CTs:
80mA Solid-Core or 5A:80mA CT Convertors
Approvals:
Measurement Canada, NYPSC, Maryland PSC, CDFA
PowerHawk 6320

PowerHawk 6320

A very high density (50 CT inputs) revenue-grade, multi-point electrical meter suitable for regulated markets. ‍

Inputs:
50
Config:
20 x 2-phase, 10 x 3-phase + 10 x 2-phase
Voltage:
120V CV, 90-300V Vref
CTs:
80mA Solid-Core or 5A:80mA CT Convertors
Approvals:
Measurement Canada, CDFA
PowerHawk 6412

PowerHawk 6412

A higher density (24 CT inputs) revenue-grade, multi-point electrical meter that uses 5AMP CTs and is approved by Measurement Canada for use in Canada.

Inputs:
24
Config:
24 x 1-phase, 12 x 2-phase, or 8 x 3-phase
Voltage:
120V CV, 90-300V Vref
CTs:
5A Solid-Core
Approvals:
Measurement Canada
Regulated Markets
Non-Regulated Markets
GATEWAY 1000

GATEWAY 1000

A highly flexible (12, 24, 36, or 48 CT inputs) revenue-grade, multi-point electrical meter for regulated markets.

Inputs:
12, 24, 36, or 48
Voltage:
2 VRef, 300V max
CTs:
100mA Solid-Core
Approvals:
Measurement Canada (Pending)
GATEWAY 8000

GATEWAY 8000

A highly flexible (6 12, 24, 36, or 48 CT inputs) revenue-grade, multi-point electrical meter for regulated markets.

Inputs:
12, 24, 36, or 48
Voltage:
2 VRef, 300V max
CTs:
80mA Solid-Core or 5A:80mA CT Convertors
Approvals:
Measurement Canada, CDFA (Pending)
GATEWAY 9000

GATEWAY 9000

A highly flexible (6, 12, 18, or 24 CT inputs) revenue-grade, multi-point electrical meter for regulated markets.

Inputs:
6, 12, 18, 24
Voltage:
2 VRef, 300V max
CTs:
80mA Solid-Core or 5A:80mA CT Convertors
Approvals:
Measurement Canada
PowerHawk 6103

PowerHawk 6103

A low density (6 CT inputs) revenue-grade, multi-point electrical meter suitable for regulated markets.

Inputs:
6
Voltage:
120V CV, 90-300V Vref
CTs:
100mA Solid-Core
Approvals:
Measurement Canada, NYPSC, Maryland PSC, CDFA
PowerHawk 6112

PowerHawk 6112

A high density (24 CT inputs), multi-point electrical meter that uses 100mA solid-core CTS and suitable for use in regulated markets in Canada and the US.

Inputs:
24
Voltage:
120V CV, 90-300V Vref
CTs:
100mA Solid-Core
Approvals:
Measurement Canada, NYPSC, Maryland PSC, CDFA
PowerHawk 6303

PowerHawk 6303

A low density (6 CT inputs) revenue-grade, multi-point electrical meter suitable for regulated markets. ‍

Inputs:
6
Voltage:
120V CV, 90-300V Vref
CTs:
80mA Solid-Core or 5A:80mA CT Convertors
Approvals:
Measurement Canada, NYPSC, Maryland PSC, CDFA
PowerHawk 6312

PowerHawk 6312

A high density (24 CT inputs), multi-point electrical meter that uses 80mA solid-core CTS and suitable for use in regulated markets in Canada and the US.

Inputs:
24
Voltage:
120V CV, 90-300V Vref
CTs:
80mA Solid-Core or 5A:80mA CT Convertors
Approvals:
Measurement Canada, NYPSC, Maryland PSC, CDFA
PowerHawk 6320

PowerHawk 6320

A very high density (50 CT inputs) revenue-grade, multi-point electrical meter suitable for regulated markets. ‍

Inputs:
50
Voltage:
120V CV, 90-300V Vref
CTs:
80mA Solid-Core or 5A:80mA CT Convertors
Approvals:
Measurement Canada, CDFA
PowerHawk 6412

PowerHawk 6412

A higher density (24 CT inputs) revenue-grade, multi-point electrical meter that uses 5AMP CTs and is approved by Measurement Canada for use in Canada.

Inputs:
24
Voltage:
120V CV, 90-300V Vref
CTs:
5A Solid-Core
Approvals:
Measurement Canada
No items found.
GATEWAY 3000

GATEWAY 3000

A highly flexible (12, 24, 36, or 48 CT inputs) revenue-grade, multi-point electrical meter suitable for energy management in non-regulated markets. ‍

Inputs:
12, 24, 36, or 48
Voltage:
2 VRef, 300V max
CTs:
333mV Split-Core
Approvals:
Non-Regulated
PowerHawk 4206

PowerHawk 4206

A low density (6 CT inputs) revenue-grade, multi-point electrical meter suitable for energy management in non-regulated markets. ‍

Inputs:
6
Voltage:
120V CV, 90-300V Vref
CTs:
333mV Split-Core
Approvals:
Non-Regulated
PowerHawk 4224

PowerHawk 4224

A higher density (24 CT inputs) revenue-grade, multi-point electrical meter suitable for energy management in non-regulated markets. ‍

Inputs:
24
Voltage:
120V CV, 90-300V Vref
CTs:
333mV Split-Core
Approvals:
Non-Regulated
